Product Details:
|
| Place Of Origin: | Shandong, China | Condition: | New |
|---|---|---|---|
| Batch Time(times/hour):: | 10 Times/hour | Total Capacity(L): | 35L |
| Marketing Type: | New Product 2021 | Warranty: | 3 Year |
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pum | Brand Name: | HHS |
| Voltage: | 380V,Customer's Request,380V/50HZ | Power(w): | 55KW |
| Type: | Rubber Kneader,Electric Heating Water Cooling | Color: | Orange,Blue Or Green,customized |
| Application: | Rubber / Plastic Mixing,Mixing Rubber Or Press Rubber Sheet | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Weight: | 6000KG | Dimension(l*w*h): | 3200*1900*2950mm |
| High Light: | Pneumatic Control Rubber Kneader Machine,O-Shaped Ring Rubber Kneader Machine,CE Oil Seal Ring Rubber Kneader |
||
This rubber kneader machine is a type of dispersion kneader, consist of pneumatic control system, electric control system, tilting mechanism, mixing chamber, main driving system, dust sealing device, thermal resistance, rotor and cooling/heating system. You can choose the right model according to your needs.
Easy operation with convenient maintenance.
Low labor intensity and low energy consumption.
The series of rubber kneader machines are main used for molding and mixing the materials of natural rubber, synthetic rubber, recycled rubber or plastic, or blending rubber and plastic. They are also suitable for mixing a variety of low viscosity materials.
It is used widely in sealed fittings factory, rubber and plastic products factory, also applies to blend in paints, dyes, ceramics, medicine, tapes, movie film line etc..
This machine is the best new-type mixing equipment in rubber and plastics industry. The performance indicators are at or near advanced level of similar products in domestic and abroad.
1.Rubber tires , tire plant,
2.Cable plant,
3.Rubber product for automobile,sealed fittings factory (oil seal, body seal, gasket, belt, hose, tube and etc)
4.Electric wires,cable plant (rubber, plastic and wire harness and etc)
5.Adhesive tape & hose factory,
6.Rubber shoes factory,
7.Belt (power transmission belt, conveyor belt and etc)
8.Roll (rubber, plastic, printing, copying machine and etc)
9.Rubber product for medical (plug, cap, glove, dental and etc)
10.Sporting goods (golf ball, athletic balls and etc)
11.Food (chewing gum)
12.Manufacture of abrasives
13.Graphite compounds
14.Sealing compounds
15.Hard metal compounds
parameters
Main technical parameters:
| Model | X(S)N-20*32 | X(S)N-35*30 | X(S)N-55*30 | X(S)N-75*30 | X(S)N-110*30 |
| Total Volume (L) | 45 | 75 | 125 | 175 | 250 |
| Working Volume (L) | 20 | 35 | 55 | 75 | 110 |
| Power(KW) | 30 | 55 | 75 | 110 | 185 |
| Tilting Power(KW) | 1.5 | 2.2 | 2.2 | 3.0 | 7.5 |
| Tilting Angle | 140° | 140° | 140° | 140° | 140° |
| Rotational Speed (r/min) | 40/32 | 40/32 | 40/32 | 40/32 | 40/32 |
| Size(mm) | 3100*1300*2450 | 3200*1900*2945 | 3300*1900*2900 | 3760*2143*3135 |
4075*2712*3580 |
detailed pictures
