Product Details:
|
| Type: | Vulcanizer | Colour: | All Colour |
|---|---|---|---|
| Voltage: | Customized | Power(W): | 11KW*2 |
| Temperature: | Max 300 Degree | Plates: | 300-2100mm |
| Hot Plates Material: | Q-235 Material. | Heating: | Electricity , Steam Heating , Conduction Oil Heating . |
| Weight: | 50000 Kg | ||
| High Light: | 11KW Tire Tread Making Equipment,Tyre Precure Vulcanized Molding Machine,Tread Vulcanized Molding Machine |
||
1. Automatic ascending,bumping,pressurization and descending operations.
2. High speed ascending, pressure retaining for better product quality.
3. Fast release valve for fast descending but incorporates adjustable speed.
4. Depressurization can be adjusted to suit thickness of products.
5. Special designed platens for even heating area.
6. The above features can be incorporated in automatic and semi-automatic machines.
| Type | XLB-Q3600X410 | XLB-Q5000X670 | |
| Total pressure | 5.00 | 8.00 | |
| Plate size | 3600x410 | 500x670 | |
| Clearance | 200 | 200 | |
| Piston diameter | 5x285 | 8x285 | |
| Work pressure | 15 | 15 | |
| Steam pressure | 1.0 | 1.0 | |
| Motor power | 7.5+5.5 | 5.5+11 | |
| Operation mode | PLC system | ||
| Heating mode | Electric/steam .oil heating | ||
