Product Details:
|
| Type: | Vulcanizer | Colour: | All Colour |
|---|---|---|---|
| Voltage: | Customized | Power(W): | 11KW*2 |
| Temperature: | Max 300 Degree | Plates: | 300-2100mm |
| Hot Plates Material: | Q-235 Material. | Heating: | Electricity , Steam Heating , Conduction Oil Heating . |
| Weight: | 50000 Kg | ||
| High Light: | Q235 Material Tyre Tread Vulcanizing Press,Frame Type Tyre Tread Vulcanizing Press,300mm Plate Vulcanizing Press |
||
Specifications
Tyre Tread Vulcanizer
1.Convenient and practical
2.High automation level
3.High production
Main characteristic:
1.unit treading working pressure is very high greater than 81kg/cm2.Ensure the tread density,improved wear-resisting performance.
2.Transform the hydraulic systerm process.Reducing the power. Save the energy,total power only 7.5kw.
3.Use PLC control,the automation control.
4.Can be easily recycled the overflow of rubber,reduce the cost.
5.Smooth operation,less easyworm parts.
Technical data
| Type | XLB-Q | XLB-Q | XLB-Q | XLB-Q | XLB-Q |
| Performance Parameter | 1200*2700*1 | 1300*1300*1 | 1400*8000*2 | 1400*2500*1 | 2000*2500*1 |
| Nominal molding power | 8.50 | 12.00 | 34.00 | 12.00 | 14.00 |
| Piston stroke | 250 | 250 | 400 | 500 | 2550 |
| Hot Plate Pressure Per Unit Area | 2.6 | 3.08 | 3.10 | 3.40 | 2.88 |
| Working layer number | 1 | 1 | 2 | 1 | 1 |
| (KW)Main motor power | 5.5 | 7.5 | 37.5 | 19 | 22 |
| (mm)Plate clearance | 250 | 250 | 200 | 500 | 250 |
| (mm)Overall Size | 2700*1860*2600 | 3000*2100*3360 | 8000*2400*3800 | 2500*3100*3600 | 3520*2900*3550 |
| (KG)Weight | 20000 | 26000 | 121000 | 22000 | 55000 |
| (mm)Hot Plate Specs | 1200*2700 | 1300*3000 | 1400*80000 | 2000*2500 | 2000*3200 |
