Product Details:
|
| Place Of Origin: | Shandong, China | Max Working Press: | 0.8 MPa |
|---|---|---|---|
| Warranty: | 1 Years | Core Components: | PLC, Pressure Vessel |
| Color: | Customer's Requirements | Advantage: | Full Automatic |
| Certification: | ASME CE, ASME CE | Key Selling Points: | Easy To Operate |
| High Light: | 18 Tyres Retreading Machine,Double Envelope Curing Tyres Retreading Machine,PLC Tire Retreading Machine |
||
| Temperature | 112 ~ 117°C |
| Capacity | 16~18 tyres |
| Cure pot pressure | 0.45 ~ 0.5Mpa |
| Inner tube pressure | 0.65 ~ 0.7 Mp |
| Envelope working pressure | 0.2 Mpa |
| Total power electricity | 65 Kw |
| External dimensions (L × W × H) | 1800x2100x2100 (mm) |
2.Function Description
a.Suitable for double-envelope curing, rim&tube curing and envelope-sealing ring curing
b.Display the curing parameters and the working state of kay components
c.Alarm when fault happens also has fault analysis
d.Adopt isolation transformer to keep PLC work smoothly
e.Heating tube heat alternately when start curing,maintain temperature balance
d.Optional Tire size:5"-15", 15"-22.5", 22.5"-25", 25"-33".
Can be designed according to your output.
3.The process as follow
tyre clean firstly dry tyre → inspecting tyre → buffing tyre → buffing outer wound of tyre → buffing inner wound of tyre → secondly inspecting tyre → repair inner wound → brushing adhesive on roof of tyre → secondly drying tyre → repair outer wound → affix middle rubber piece → tread building →assemble envelop → assemble inner tyre → assemble curing rim → inspecting inner tyre and curing rim → curing→ disassemble curing rim→ disassemble inner tyre → disassemble envelop → inspect end product → embellish tyre→ store tyre.
4.Service
We provide the whole set tire retreading solutions for clients who want to set up a new retreading factory/plant for used tyre recycling business.Such as Free Layout your workshop, Free Training your worker.
Contact Person: Miss. Sophie
Tel: +8613573826806
