Product Details:
|
| Place Of Origin: | Shandong, China | Brand Name: | HHS |
|---|---|---|---|
| Model Number: | XQL-120 | Voltage: | 220V /380V /440V |
| Dimension(L*W*H): | 2300X1500X2530 | Certification: | CE,ISO9001 |
| Warranty: | 1 Year | Type: | Rubber Cutting Machine |
| Weight: | 2000kg | Power(W): | 11KW |
| Product Name: | High Quality Vertical Rubber Bale Cutter | Time Of Blade Cutting: | 13-16 |
| High Light: | CNC Rubber Slitter Machine,Vertical Rubber Slitter Machine 11kw,Numerical Control Rubber Bale Cutter |
||
construction of cutting machine : vertical type rubber bale cutter , horizontal type rubber cutter machine
size of vertical type rubber cutter machine : XQL-8T,XQL-12T , XQL-16T, XQL-18
size of horizontal type rubber cutter machine : 400 , 600, 800 , 1000, 1400
Vertical gantry hydraulic cutting machine is mainly composed of cutter, frame, working cylinder, base auxiliary table and hydraulic system, electrical system and other parts. The base below the glue cutter is equipped with nylon pad to protect the blade of the glue cutter. When cutting the material, put the material under the cutter, and then press the start button, the glue cutter will fall down along the slide way on the rack under the drive of the piston rod to cut the material. The upper and lower limit switches on the frame can control the lifting distance of the cutter in order to save time and improve work efficiency. This product machine model is various, manual, semi-automatic, automatic, NUMERICAL control, guardrail, card material, pressing material and so on, welcome to customize.
Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
welcome to visit our factory!
