Product Details:
|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Video Technical Support | Type: | Open Mixing Mill |
|---|---|---|---|
| Roller Hardness: | 50~60HRC | Bush: | Nylon Bush,bearing Bush,ball Bearing Bush |
| Voltage: | 380V,Customer's Request,380V/50HZ,220/380V,AC380V | Power(w): | 37kw,4.5KW,20KW,5KW For Lab Two Roll Mill |
| Weight: | 5200kgs,1000kg,2T | Dimension(l*w*h): | 1100*700*1200mm,1226x830x1295mm,1*1.1*1.4(M),1100*650*1500,1160*920 *1370mm |
| Warranty: | 1 Year | Condition: | New |
| High Light: | 75KW Reclaimed Rubber Refiner Mill,32m/Min Rubber Refiner Mill,Grease Lubricating Rubber Milling Machine |
||
We can provide you a full set production line equipments for reclaimed rubber production from waste radial tire.Production list:
Tire bead ring cutter / Strip cutter / Lump cutter / Wire separator
Rubber cracker mill
Dynamic devulcanizer / Devulcanizing autoclave
Rubber powder cooling machine.
Rubber strainer
Rubber refiner
Winding machine
Production capacity: 500kgs/per hour or 1000kgs per hour as per your request.
Technical spec.:
| 1.Type | XKJ-450*800/1000 | XKJ-480*1000 |
| 2.Diameter of front & rear roller | 450mm/510mm | 480mm/610mm |
| 3.Working length of rollers | 800mm / 1000mm | 1000mm |
| 4.Roller materials & structure | Chilled casted iron & smooth roller | Chilled casted iron & smooth roll |
| 5. Rotation speed of front roller | 32m/min; | 30m/min |
| 6.Motor power | 55KW / 75KW | 75KW / 90KW / 110KW |
| 7.Speed reducer | Hardened teeth speed reducer | Hardened teeth speed reducer |
| 8. Roller support type: | bearings | bearings |
| 9. Lubricating type: | Grease lubricating | Grease lubricating |
| 10.Weight | 10 tons | 16.5 tons |
The rollers are made of chilled cast iron with wear-resistant hard surfaces. The two rollers are smooth ones with bored cavities and can be cooled homogeneously. The protective device is provided to protect the main parts from damage due to overload. In case of emergency, the safety rod is pulled down and the rollers will be stopped immediately.
Besides providing a full line equipment, we can also provide you with a full set of technical support
1. Motor&Electrical Components equiped with "SIEMENS" "MITSUBSHI" "CHINT",etc.
2. Imported PLC auto control,Safe, Seliable,Stable.
3. Patented design,energy conservation.
1. Made of chilled cast iron with vanadium and titanum alloys;.
2. Working surface Hardness:HS72±2
3. Rolls temperature and time control system:Imported PLC auto control system.
1. Hardened tooth-surface reducer, Compact structure.
2. Higher transmission efficiency.
3. Lower noise,Longer Service Life.
1. Protective cover prevent operator's hands from rolling into the roll.
2. Equipped with emergency device,provide safe and reliable emergency stop.
3. Equipped with an overload protection device to prevent the major components from being damaged due to overloading..
