3/4/5 Rolls calender machinery/ calendaring line for rubber and plastics industry

Machine application

It is used to produce various rigid, semi rigid or soft plastic films or sheets.

It can also be used to produce high filling plastic film or high filling plastic sheet.

Machine features

1.The machine is made of chilled castiron alloys,whose work surface has high hardness,so it is wear-resistant and durable.

2.While using,the steem,cooling water and heat-conducting oil can be passed into the roller's cavity,so that the working temparature can be adjusted in order to meet the technological requirement.

3.Roller space can be adjusted both by manual or electric mode.

4.Roller bearings' lubricating can adopt drier oil or dilute oil.

5.The film can infinite extend, with a high work speed, high produce capacity, good quality and uniform thickness.

6.The main machine has roll crossing, preloading and anti-bending device, the adjustment speed can be adjusted, the electric parts has PLC control.

Technical parameter

Machine specifications can be designed according to different products.

A plastics film/sheet Calendering line usually contains the following machines

(1)high-speed kneading machine and cooling mixer

(2)planet extruding machine

(3)Chain conveyer

(4)single screw extruding machine

(5) 3/4/5/6/7 calender machine

(6) 5/7 roller take off machine

(7)Two-roller plating press

(8)Segment assist machine after a calender

(9)Calendering electric control system

(10)Hot oil temperature control system

(11)Automatic single roller surface winder

(12)Broken material recovery system

Features&Pictures

Motor&Electric:

a. Equiped with "SIEMENS" "MITSUBSHI" "CHINT",etc.
b. Imported PLC auto control,Safe, Seliable,Stable.

c. Patented design, energy conservation.

Transmission System:

a. Hardened tooth-surface reducer.
b. Higher transmission efficiency; Lower noise; Longer Service Life.


Base Frame:

a. Whole casting framework,base frame welded by high quality steel,firm and durable.

b. Whole processed by pentahedron,machining center to ensure accuracy.

Rolls(Dalian Bao Feng):

a. Made of chilled cast iron with vanadium and titanum alloys.
b. Working surface Hardness:HS72±2

c. Drilled or Hollow Structure

Heating and Cooling System:

a. PLC Control the temperature.
b. High precision temperature control Heating and cooling fastly.

Nip Adjust System:

Combine Mechanical with hydraulic type nip adjust,high-precision,ensure produce thickness.

Packing & Delivery

Step 1: Machine main body and accessories rust preventing oil treatment.
Step 2: Wooden Carton or stretch film packing.
